USC-DP Wall-Mount Charger
- Wall-Mount EV Charger
- One Step Installation
- RGB LED Indicator
- Type 2 Connector
- RCD protection: Type B(30mA AC+6mA DC)
- Anti-welding protection, IP65, Leakable Current Protection
- EV Charging Cable Wrapped in TPE Jacket
- Certified with ICCB, FCC, RoHS
Customization Upon Inquiry
SKU:
USC-DPProduct Spec
| Model Name | USC-DP |
|---|---|
| Power Supply | Single Phase |
| Rated Voltage | 110V-240V AC |
| Rated Current | 32A/40A/48A |
| Output Power | 7KW/9KW/11KW |
| Charging Connector | Type 2 |
| Cable Length | 20 ft (6 m) or 25 ft (7.62m) |
| Housing Material | Plastic PC940 |
| LED Indicator | Blue/Green/Red |
| Start Mode | Plug & Charge |
| Communication | Via App |
| Leakage Current Protection | CCID 2 |
| Enclosure Rating | IP65 |
| Electrical Protection | Leakage current protection; Impact resistance, Over current protection, Ground protection, Surge protection, O/U voltage protection, O/U frequency protection, Over temp protection |
| Certification | FCC, RoHS, UL |
| Installation Type | Wall-Mount |
| Working Temperature | -86°F ~122°F (-65℃〜+50℃) |
| Working Humidity | 5% - 95% |
| Working Altitude | < 6561ft (2000m) |
| Product Dimensions | 290 x 100 x 95 |
| Package Dimensions | 405 x 280 x 235 (H*W*D) |
| Net Weight | 9.92 lb (4.5 kg) |
| Gross Weight | 12.78 lb (5.8 kg) |
| External Package | carton |
